MOBILCUT STATE LINE / 7,5 kW
stationary machine with arch guiding frame
- manual feed of cutting unit
- manual feed of saw (left / right)
Stationary machine MOBILCUT STATE LINE for cross-cutting of packages with max. dimensions 130 x 130 cm (W x H) with movable cutting unit.
Ideal solution when room space is limited. Easy and quick installation. Perfectly fills the price gap between cheaper portable saws and automatic stationary lines.
Cutting unit lowered / raised manually thanks to comfortable grip, manual saw feed left / right using a crank.
|electric 3x400V / 50 Hz / 2920 rpm, direct power transmission
|Standard package size
|130 x 130 cm (W x H), packages with a length of max. 6m
|Other dimensions available
|Guiding of the cut
|rigid arch guiding 100 x 50 mm, high stability of cut
|saw moves with operator / stationary package
|scraper steel / carbide tipped chain
|solid steel, high frequency hardened or with additional one / two-side stellite plating
|+/- 2 mm
|manual using a crank
|Measuring device available
|manual using buttons / switches
|cross-cutting of packages with accuracy +/- 2 mm while room space is limited
Solid steel, high frequency hardened guide bars or with additional one or two-side stellite plating.
A form (Google Forms) for the MOBILCUT line so we can learn about your capabilities and needs, which will allow us to select the right solution for your plant:
