PROFICUT exact / 7,5 kW
stationary saw with arch guiding frame, to be built in

  • can be built into existing line
  • stability of the cutting process thanks to arch guiding frame

Stationary, electrically powered chainsaw PROFICUT exact for cutting lumber packages and boards up to 130 x 130 cm (W x H). The main advantages of the machine inlcude: one-man servicing, high precision +/- 2 mm and stability during cutting process due to a guiding bow.

Perfect for building into an already existing processing line and upgrading with additional transport or measuring systems.

Technical data
Power7,5 kW
Motorelectric 3x400V / 50 Hz / 2920 rpm, direct power transmission
Standard package size (W x H)130 x 130 cm (guide bar 200 cm)
Other dimensions availableno
Cut feedmanual
Guiding of the cutrigid arch guiding
Saw typestationary
Chain typescraper chain / carbide tipped chain
Guide barsolid steel, high frequency hardened or with additional one or two-side stellite plating
Cutting performance1,5 min/m²
Cutting accuracy+/- 2 mm
Saw/material drive
Measuring device available
Control systemrelay, automatic switch
Applicationstationary cross-cutting of packages
Other
  • weight: approx. 260 kg
  • rail head chain tensioner, fully automatic chain lubrication, easy chain tension, gear oil pump, precise oil dose regulation due to control valve, lubrication from cut material side extends life-span of cutting unit parts
  • comfortable grip to lower / raise the cutting unit, especially long guide bars
Option
  • bigger, 20l oil tank
  • roller tables for package transportation
  • laser light for cut position
  • conveyors for waste transportation
  • containers for waste removal
  • output for dust collecting system
Strengths
proficutexact-glowica-m x
proficutexact-glowica-m
Massive rail head which includes:

- comfortable chain tension system (red knob)
- saw chain vibration damping system (through pulley)
- fully automatic chain lubrication - oil tank, gear oil pump, precise oil dose regulation due to control valve; lubrication from the cut material side
ecostar-uklad-tnacy-s x
ecostar-uklad-tnacy-s
Massive cutting chain with 20 mm pitch for optimum removal of chips, guarantees smooth and level surface after cutting.

Definitely longer durability and visibly better material surface after cutting compared to chains with a pitch of 0,404".

Solid steel, high frequency hardened guide bars or with additional one or two-side stellite plating.
proficutexact-luk-prowadzacy-m x
proficutexact-luk-prowadzacy-m
Arch guide frame for better guiding of cutting unit, cutting accuracy: +/- 2 mm.
proficutexact-portal-m x
proficutexact-portal-m
Wide vertical portal as protection for the operator.
proficut-uchwyt-m x
proficut-uchwyt-m
Comfortable grip to lower / raise the cutting unit, especially long guide bars

Additional switch in the handle for operator safety.
proficutexact-pulpit-m x
proficutexact-pulpit-m
Ergonomically designed steering console, easy operation of the machine together with the rolling table, measurement system, conveyors for waste removal, etc.
ecostar-skrzynka elektryczna-s x
ecostar-skrzynka elektryczna-s
Siemens electrical components.
proficut-laser-m x
proficut-laser-m
Laser light showing cut position (option).
