PROFICUT strong

PROFICUT strong / 11 kW
industrial chainsaw for cross-cutting packages and roundwood

  • version with strengthened construction and the 11 kW engine
  • possibility to mount guide bar up to 250 cm

Mobile, electrically powered chainsaw PROFICUT strong used to cut lumber packages, particle boards and round timber.

In comparison to PROFICUT light, machine has reinforced construction, wider front bumper and more powerful motor 11 kW, which allows the usage of machine in hardest conditions.

Technical data
Power11 kW
Motorelectric 3×400 V / 50 Hz / 2920 obr./min, direct power transmission
Standard package size (W x H)130 x 130 cm (guide bar 200 cm)
Other dimensions availableyes (guide bars: 100, 120, 150, 170, 225, 250 cm)
Cut feedmanual
Guiding of the cuttwo stabilization bars for better accuracy of cutting
Saw typemobile saw / stationary package
Chain typescraper chain / chipper chain / carbide tipped chain
Guide barsolid steel, high frequency hardened or with additional one or two-side stellite plating
Cutting performance1,8 min/m²
Cutting accuracy+/- 4 mm
Saw/material drivemobile saw / stationary material
Measuring device availableno
Control systemrelay, automatic switch
Applicationclean cuts on packages and logs, cutting on the spot
Other
  • weight: approx. 220 kg, reinforced construction
  • wide front plate for easy, perpendicular positioning of the machine, height 750 mm,
  • rail head chain tensioner
  • easy, toolless saw chain tension and replacement
  • fully automatic chain lubrication, gear oil pump, precise oil dose regulation due to control valve, lubrication from cut material side extends life-span of cutting unit parts
  • comfortable grip to lower / raise the cutting unit, especially long guide bars
  • full-tire wheels, easy transport of the machine
  • footrest for operator’s comfort
Option
  • TWIN-L – package positioning frame, which allows usage of saw both mobile and stationary
  • sliding mechanism of the cutting unit (left / right) – for precise positioning of the guide bar on the cutting line, feed approx. 4 cm
  • point laser helpful in setting the saw on the cutting line
  • ergonomic system that facilitates lifting of longer guide bars (from 170 cm cutting length)
Strengths
proficut-glowica-m x
proficut-glowica-m
Massive rail head which includes:

- comfortable chain tension system (red knob)
- saw chain vibration damping system (through pulley)
- fully automatic chain lubrication - oil tank, gear oil pump, precise oil dose regulation due to control valve; lubrication from the cut material side
ecostar-uklad-tnacy-s x
ecostar-uklad-tnacy-s
Massive cutting chain with 20mm pitch for optimum removal of chips, guarantees smooth and level surface after cutting, thickness of the link 3 mm.

Guide bar with stellite layer on one or both sides for optimum life-span of the cutting system.
proficut-stabilizatory-m x
proficut-stabilizatory-m
Two stabilization bars for better guiding of the bar, cutting accuracy: +/- 4 mm with level surface.

When leveling end of a package, one stabilization bar stiffens the guide bar increasing cutting accuracy.
proficut-strong-zderzak-m x
proficut-strong-zderzak-m
Wide front plate for easy perpendicular positioning of the machine in relation to the material, 750 mm height.

Reinforced construction, weight approx. 220 kg.
proficut-uchwyt-m x
proficut-uchwyt-m
Comfortable grip to lower / raise the cutting unit, especially long guide bars.

Additional switch in the handle for operator safety.
proficut-kola-m x
proficut-kola-m
Full-tire wheels, easy transport of the machine.
proficut-stopka-m x
proficut-stopka-m
Footrest for operator's comfort.
proficut-laser-m x
proficut-laser-m
Spot laser helpful when setting the saw on the cutting line (option).
proficut-uklad-przesuwu-prowadnicy-m x
proficut-uklad-przesuwu-prowadnicy-m
Sliding mechanism of the cutting unit (left / right) - for precise positioning of the guide bar on the cutting line, feed approx. 4 cm (option).
proficut-uklad-powrot-prowadnicy-m x
proficut-uklad-powrot-prowadnicy-m
Ergonomic system based on a gas spring, which makes it easier to lift longer guide bars (from 170 cm cutting length).
ecostar-skrzynka elektryczna-s x
ecostar-skrzynka elektryczna-s
Siemens electrical components.
Video

How to choose the right guide bar length?
thumbnail of proficut-dlugosc-prowadnicy-pakiety
How to choose the right guide bar length – packages
thumbnail of proficut-dlugosc-prowadnicy-okraglaki
How to choose the right guide bar length – round wood
