ULTRACUT / 15 kW
stationary automatic line with precise package carriage

  • easy transport of short and uneven packages
  • trouble-free disposal of longer waste

Thanks to parallel linear bearing guide of the cutting unit and exact package positioning with the precisely guided carriage, a maximum cutting accuracy of +/- 1 mm is guaranteed.

Combination of series cuts function and saw kerf opening significantly accelerates and automates the cutting process.

Technical data
Cutting motorelectric 15 kW / 3x400V / 50 Hz / 2920 rpm
Standard package size120 x 120 cm (W x H)
Other dimensions availableyes
Cut feedgear motor with inverter
Guiding of the cutparallel precision linear bearing guide system
Saw typestationary saw unit / package moves
Chain typescraper chain / carbide tipped chain
Guide barsolid steel, stellite inlay, EXPERT-LINE execution also available
Cutting performance1,2 min/m²
Cutting accuracy+/- 1 mm
Saw feedmotor with inverter
Measuring device availableyes
Control systemSPS
Applicationefficient cross-cutting of packages with +/- 1 mm accuracy
Other
  • absorbing and tensioning system in the rail head, automatic tension of the saw chain by a gas spring
  • fully automatic chain lubrication – 20l aggregate
  • exhaust connection
  • saw chain monitoring system
  • package height control system
  • automatic reference cut
  • advanced control systems with series cut function
Option
  • saw kerf opening system which faciliates withdrawal of guide bar from package
  • laser light for cut position
  • package strapping device
  • pneumatic package holding down appliance on both sides of the guide bar
  • conveyors for waste transportation, containers for waste removal
  • plastic curtains which blocks waste discarded during cutting
  • side package pressure pad
  • tablet remote control
Strengths
ultracut-smarowanie-m x
ultracut-smarowanie-m
Automatic lubrication of the cutting unit, 20l oil tank, precise regulation of oil dosage.
cutstar-masywna-glowica-m x
cutstar-masywna-glowica-m
Massive rail head with shock absorption of the saw chain.

Automatic chain tension thanks to a gas spring.

Saw chain condition monitoring system.

cutstar-wprowadzanie-pod-katem-m x
cutstar-wprowadzanie-pod-katem-m
The guide bar starts to cut the package at a slight angle, ensuring smoother "cutting into" the package upper layers and reducing cutting unit parts wear.
x
cutstar-dociski-m x
cutstar-dociski-m
Package holding down appliance on both sides of the guide bar.

Watch here youtube icon
cutstar-prowadzenia-liniowe-m x
cutstar-prowadzenia-liniowe-m
Massive parallel precision linear bearing guide system for precise and stable guiding of the guide bar with saw chain.
ultracut-uklad-pomiarowy-m x
ultracut-uklad-pomiarowy-m
Automatic measuring system which allows to cut packages with accuracy of +/- 1 mm.
ultracut-wozek-pakiety-m x
ultracut-wozek-pakiety-m
Movable package carriage, ensuring exact positioning of cut material.

Kerf opening system - raises packages after cutting, faciliating withdrawal of guide bar. The most effective cross-cutting in combination with serial cutting function.
ultracut-odwiorowywanie-m x
ultracut-odwiorowywanie-m
Prepared output for dust collecting system.
cutstar-systemy-transportu-odpadow-m x
cutstar-systemy-transportu-odpadow-m
Waste removing systems.
ultracut-pulpit-sterujacy-m x
ultracut-pulpit-sterujacy-m
Functional and clear steering consoles / remote control.
cutstar-laserowa-projekcja-ciecia-m x
cutstar-laserowa-projekcja-ciecia-m
Laser light showing cut position.
cutstar-kurtyny-swietlne-m x
cutstar-kurtyny-swietlne-m
Light curtains that increase machine operation safety.
ultracut-rolki-pionowe-m x
ultracut-rolki-pionowe-m
Vertical supports for easy and precise positioning of the packs during loading.
x
ultracut-obwiazywarka-m x
ultracut-obwiazywarka-m
Optional: automatic package strapping with plastic bands.
