LOGSTAR / 11 or 15 kW
stationary machine with hydraulic cutting unit feed

  • power transmission through a belt system
  • perfect for building into an automated line

Electro-hydraulic station has been designed for efficient cross-cutting of round timber. Perfect for building into an automated line. At the client’s request, the machine can be supplied with additional equipment, e.g. hydraulic clamping device which holds down logs during cutting or a hydraulic moveable base.

Technical data
Power11 or 15 kW
Motorelectric 3x400V / 50 Hz / 2920 rpm, power transmission through belt system
Maximum log diametermax. 100cm
Other diameters availableyes
Cut feedhydraulic, working pressure 50 bar
Guiding of the cutstabilizer
Saw typestationary saw / material moves
Chain typechipper chain / carbide tipped chain
Guide barsolid steel, stellite inlay
Cutting performanceapprox. 18 s/m2
Material driveV-rollerway (in option)
Saw drivegear motor (in option)
Measuring device availableyes (in option)
Control systemsrelay / SPS
Applicationefficient cross-cutting of logs of bigger diameters
Other
  • weight approx. 360kg
  • rail head chain tensioner, fully automatic chain lubrication, precise regulation of oil dose due to control valve, gear oil pump, lubrication from the side of cutting material enhancing the longevity of cutting unit parts (lubrication from the rail head)
Option
  • manual or electronic measuring device
  • laser light for cut position
  • hydraulic system of raising and lowering table rolls
  • hydraulic log clamping device
  • hydraulic movable base
  • conveyors for waste removal
  • bigger, 20l tank with pump and oil level sensor for lubrication of cutting unit
  • V-rollerway
Strengths
logstar smarowanie
Automatic chain lubrication, precise regulation of oil dose due to control valve, gear oil pump.

20l oil aggregate with 0,24 kW motor as option.
Rail head tensioner preventing cutting chain from breaking.

Easy tension of saw chain.
logstar stabilizator
Stabilizer for precise and stable guiding of cutting unit, cutting accuracy: +/- 5mm.
logstar lancuchy
Massive saw chain with 3 mm driving link thickness and 15 or 20 mm pitch for optimal removal of chips.

Chipper type execution enables efficient round timber cutting.
logstar konstrukcja
Massive construction, saw chain drive through a belt system.
logstar dociski
Options include among others hydraulic clamping device which holds down logs during cutting and hydraulic movable base.
pulpit logstar_1
Functional and clear steering console.
