PROFICUT PE exact

PROFICUT PE exact
industrial plastic cutting station for angular cuts

Technical Data Spare parts
  • arch guide for precise guiding of the cutting unit, cutting accuracy: +/- 2 mm
  • 7,5 up to 15 kW motor, possibility of cutting a pipe with max. diameter of 1600 mm at an angle of 45 degrees

Stationary, electrically powered PROFICUT PE exact chainsaw for cross-cutting plastic pipes. It allows you to quickly cut the material, also at angle. Perfect for companies related to the production, assembly of plastic components and recycling.

The saw can cut not only pipes but also solid plastic materials. The smooth and even surface after cutting, ensured by special PLASTICUT saw chains, facilitates further processing of material.

Ask for offer
Call Now 0048618638088
Technical data
Power7,5 / 11 / 15 kW
Motorelectric 3×400 V / 50 Hz / 2800 rpm, direct power transmission
Standard diametermax. 900 mm (guide bar 200 cm) at an cutting angle of 45°
Other dimensions availablefor larger diameters (more than 900 mm) we recommend special solutions
Cut feedmanual / electric
Guiding of the cutarch guide which increase cutting accuracy
Saw typestationary solution / mobile material
Chain typespecial saw chain PLASTICUT for cutting plastic
Guide barone or two-side stellite plating
Cutting performanceapprox. 1 min when cutting Ø 100 cm pipe, depending on the cut material
Cutting accuracy+/- 2 mm
Saw/material drivemanual / electric
Measuring device availableyes
Control systemmanual / semi-automatic
Applicationcross-cutting of plastic profiles, angled cuts
Other
  • weight: approx. 270 kg (without the material frame)
  • absorbing and tensioning system in bar head
  • easy and tool-less chain replacement
  • fully automatic chain lubrication, gear oil pump, precise oil dose regulation due to control valve, lubrication from cut material side extends life-span of cutting unit parts
  • lubrication / cooling using oil or compressed air
  • comfortable grip to lower / raise the cutting unit, especially long guide bars
  • additional safety switch for the second person, evaluating the working conditions on the other side of the material
Option
  • point laser helpful in setting the material on the cutting line
  • safety fence, light curtains
Strengths
PROFICUT light głowica
Massive, cast aluminium bar head which includes:

- comfortable chain tension system (red knob)
- saw chain vibration damping system (through pulley)
- fully automatic chain lubrication - oil tank, gear oil pump, precise oil dose regulation due to control valve; lubrication from the cut material side
uniblock-pe-lancuch-tnacy
Massive cutting chain with 15 mm pitch for optimum removal of chips, guarantees smooth and level surface after cutting.

One or two-side stellite plating for optimal lifespan.
uniblock-pe-luk-prowadzacy
Massive arch guide for precise feed of the cutting unit, cutting accuracy: +/- 2 mm.
proficut-pe-exact-miter
Miter unit enables angled cuts.
uniblock-pe-uchwyt
Comfortable grip to lower / raise the cutting unit, especially long guide bars.

Additional switch in the handle for safety of the operator and people nearby.

Additional switch (with a 10 m cable) for second person to assess the work safety on the other side of cut material.
proficut laser
Spot laser helpful when setting the saw on the cutting line (option).
uniblock-pe-pulpit
Comfortable and clear control panel.
skrzynka elektryczna
Siemens electrical components.
