twinPAPER-E

twinPAPER-E / 11 kW
industrial cutting station with rotary table for larger diameters, with electric feed

Technical Data Spare parts
  • equipped with stabilizer which stiffen the cutting unit during cutting, accuracy +/- 3 mm
  • 11 kW motor, possibility of cutting rolls with a maximum diameter of 1900 mm

twinPAPER-E saw for cutting paper rolls – crosscut station with a rotary table, with electric feed of the cutting unit.

twinPAPER-E provides economical cutting of paper rolls while maintaining a high quality surface after cut. The rotation of the roll during the cutting process allows many times faster cutting and significantly extends the lifespan of cutting unit parts.

Ask for offer
Call Now 0048618638088
Technical data
Power 11 kW
Motor electric 3×400 V / 50 Hz / 1400 obr./min, direct power transmission
Standard diameter max. 1600 mm (guide bar 200 cm)
Other dimensions available for larger diameters (up to 1900 mm) guide bar 250 cm
Cut feed electric
Guiding of the cut stabilization bar for better accuracy of cutting and as a operator’s protection
Saw type stationary solution
Chain type carbide tipped chain, for paper rolls
Guide bar one or two-side stellite plating
Cutting performance approx. 5 min when cutting Ø 150 cm roll, depending on the cut material
Cutting accuracy +/- 3 mm
Saw/material drive manual feed of the saw unit, electric roll rotation
Measuring device available yes
Control system manual, automatic star-delta switch
Application cross-cutting of paper rolls
Other
  • weight: approx. 2000 kg
  • absorbing and tensioning system in rail head
  • easy, toolless saw chain tension and replacement
  • fully automatic chain lubrication, gear oil pump, precise oil dose regulation due to control valve, 5l oil tank
  • light courtains protecting the working area of the machine
Option
  • point laser helpful in setting the saw on the cutting line
  • digital display of the length of cut rolls
  • safety fence
Strengths
głowica
Massive, steel rail head which includes:

- comfortable chain tension system (red knob)
- saw chain vibration damping system (through pulley / spring)
papercut-uklad-tnacy
Massive cutting chain with 15 mm pitch for optimum removal of chips, guarantees smooth and level surface after cutting.

One or two-side stellite plating guide bar for optimal lifespan.
stabilizator-twinpapere
Stabilization bar for better guiding of the guide bar, cutting accuracy: +/- 3 mm.
twinpapere-jednostka
Saw moves left / right mounted on bearing profiles, cutting unit is always positioned perpendicular to the cut material.
twinpapere-pulpit
Functional, ergonomic control panel.
twinpaper-rolki
Massive wheels that drive the rotation of the paper roll.

Possibility to deliver rolls using a forklift with standard forks or by using a gripper for paper rolls.
twinpaper-boczne-rolki
Side rollers to prevent material from moving during rotation.
proficut laser
Spot laser helpful when setting the saw on the cutting line (option).
twinpaper_ogrodzenie
Safety fence for increased safety within the machine (option).
skrzynka elektryczna
Siemens electrical components.
